BOE 10.1inch Outdoor High Brightness LCD Display with 1280x720 Resolution and 50K Hours Lifespan

Name: BOE 10.1inch Outdoor High Brightness LCD Display with 1280x720 Resolution and 50K Hours Lifespan
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: AV101HDM-N10-28P2
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	AV101HDM-N10-28P2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1280*1024

Brightness:

1000cd

Connector:

Contrast Ratio:

1000:1

Working Time:

50k Hours

Packaging Details:

Industrial packing

Product Description

BOE 10.1-inch Outdoor High Brightness LCD & Automotive Display - AV101HDM-N10

The AV101HDM-N10-28P2 is a 10.1-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integral WLED backlight system and touch screen capability. Designed for demanding environments, it operates within a temperature range of -30°C to 85°C and stores safely from -40°C to 90°C.

Key Features

sRGB color gamut support
Wide temperature operation range
Ultra high brightness (1000 cd/m² typical)
WLED backlight with 50,000+ hours lifespan
Built-in HX8290-B-LT*2 driver IC

Technical Specifications

Brand	BOE	Model	AV101HDM-N10-28P2
Diagonal Size	10.1 inch	Type	a-Si TFT-LCD, LCM
Pixel Number	1280(RGB)×720, WXGA, 16:9	Dot Layout	RGB Vertical Stripe
Active Area	223.68(H)×125.82(V) mm	Physical Size	233.9(H)×141.4(V)×16.1(D) mm
Luminance	1000 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	Symmetry	Response Time	30 (Max.)(Tr+Td) mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	Operating Mode	ADS, Normally Black, Transmissive
Support Color	16.7M, 86% NTSC	Light Source	10S3P WLED, 50K hrs, Without Driver
Frame Rate	60Hz	Touch Panel	Without
Interface Type	LVDS (1 ch, 8-bit), 60 pins Connector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -30°C to 85°C, Storage Temperature: -40°C to 90°C

Application Areas

Outdoor High Brightness Displays
Automotive Display Systems

Note: This model is currently in production. We strongly recommend contacting BOE or their authorized agents for the latest production status and detailed specifications before making design decisions. The information provided here is for reference purposes only.
