BOE 23.8inch Medical Imaging LCD Panel EV238FHM-N10 1920*1080Pixels 92ppi 300CD/M2 30pin 5.0V

Brand Name:	BOE
Model Number:	EV238FHM-N10
MOQ:	10pcs
Price:	USD48/PC
Packaging Details:	Industrial packing
Payment Terms:	T/T,W,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

Style:

Wide Screen High Resolution 1080*1920Pixels

Brightness:

300cd

Connector:

30PIN

Contrast Ratio:

1000:1

Working Time:

30k Hours

Screen Size:

23.8inch

Supply Ability:

3000pcs per week

Highlight:

EV238FHM-N10 Medical LCD Panel

23.8inch Medical LCD Panel

Medical Imaging LCD Panel

Product Description

BOE 23.8inch Medical imaging lcd panel EV238FHM-N10 1920*1080Pixels 92ppi 300CD/M2 30pin 5.0V

EV238FHM-N10 is a 23.8" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, WLED Backlight, Matte , TCO 6.0, ES6.0 compliant. Based on its features, einklcd recommend that this model be applied to Medical Imaging etc. According to the information stored in einklcd this model mass production on Q4, 2015, Now this model is discontinued. T We inputted this model's specification on Sep 10 2019 for the first time, and the latest update on Aug 5 2023. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of EV238FHM-N10. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand BOE

Model P/N:EV238FHM-N10

Diagonal Size: 23.8"

Panel Type: a-Si TFT-LCD, LCM

Resolution:1920(RGB)×1080, FHD 92PPI

Pixel Format: RGB Vertical Stripe

Active Area 527.04(W)×296.46(H) mm

Bezel Opening 530.2(W)×299.6(H) mm

Outline Size:543.1(W)×317.5(H) ×11.4(D) mm

Brightness: 300 cd/m² (Typ.)

Viewing Angle:89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors 16.7M 100% sRGB

Frequency: 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 2.39Kgs (Typ.)

Surface: Antiglare (Haze 25%), Hard coating (3H)

Contrast Ratio: 1000:1 (Typ.) (TM)

Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich
VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time: 14 (Typ.)(G to G)

Lamp Type: 3 strings WLED , 30K hours , Without Driver

Touch Screen:without

Application: Medical Imaging

Signal Interface: LVDS (2 ch, 8-bit) , 30 pins Connector

Input Voltage 5.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C
