LG 29" Medical LCD Panel with 2560×1080 Resolution 92 Pin Connector and 300cd Brightness Industrial Touch Screen Monitor

Name: LG 29" Medical LCD Panel with 2560×1080 Resolution 92 Pin Connector and 300cd Brightness Industrial Touch Screen Monitor
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LM290WW2-SSD1
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LM290WW2-SSD1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 2560*1080

Brightness:

300cd

Connector:

Contrast Ratio:

1000:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

industrial computer monitor

industrial panel pc touch screen

Product Description

LG 29" Medical Imaging Industrial Touch Screen Monitor

Panel Specifications

Panel Brand	LG Display	Panel Model	LM290WW2-SSD1
Panel Size	29.0"	Panel Type	a-Si TFT-LCD, LCM
Resolution	2560(RGB)*1080 (CSHD)	Pixel Format	RGB Vertical Stripe
Display Area	672.768(W)*283.824(H) mm	Bezel Opening	-
Outline Size	693.6(W)308.9(H)17(D) mm	Surface	Antiglare, Hard coating (3H)
Brightness	300 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	IPS, Normally Black, Transmissive
Best View	Symmetry	Response Time	14ms (Typ.)(G to G)
Display Colors	16.7M 99% sRGB	Lamp Type	18S4P WLED, 30K hours, Without Driver
Frequency	60Hz	Touch Screen	Without
Panel Weight	3.11/3.265Kgs (Typ./Max.)	Application	Desktop Monitor, Industrial, Medical Imaging

Interface & Environmental Specifications

Signal Interface	LVDS (4 ch, 8-bit), 92 pins, Connector
Input Voltage	10.0V (Typ.)
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C

The LM290WW2-SSD1 is a 29.0-inch diagonal a-Si TFT-LCD display panel from LG Display Co., Ltd., featuring an integrated WLED backlight system without backlight driver or touch screen capability. This industrial-grade panel operates within a temperature range of 0~50°C and can be stored at -20~60°C.

Key Features

99% sRGB color gamut for accurate color reproduction
3-side borderless design for seamless integration
WLED backlight with 30,000-hour lifespan
IPS technology for wide viewing angles
Matte anti-glare surface with 3H hard coating
Reverse interface compatibility

Important Note: This model (LM290WW2-SSD1) entered mass production in Q2 2016 and is now discontinued. We recommend contacting LG Display or their authorized agents for the latest production status and specifications before integrating this panel into your products. Information provided is for reference only and should not be used as the sole basis for decision-making.

Recommended Applications: Desktop monitors, industrial equipment, medical imaging systems, and other professional display applications requiring high-resolution, color-accurate performance.
