products details

Home Products

Samsung 23.8Inch Desktop LCD Monitor with 1920x1080P Resolution and 250cd/m2 Brightness

Name: Samsung 23.8Inch Desktop LCD Monitor with 1920x1080P Resolution and 250cd/m2 Brightness
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LTM238HL06
Price: 30.00 USD
Availability: InStock

Brand Name:	samsung
Model Number:	LTM238HL06
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

250ccd/m2

Resolution:

1920*1080pixels

Contrast Ratio:

800:1

Color:

16.7M

Working Life:

40k Hours

Connector:

30P

Touch Panel:

Without

Packaging Details:

Industrial packing

Highlight:

250Cd/M2 Desktop LCD Monitor

LCM Desktop LCD Monitor

30PIN Widescreen LCD Computer Monitors

Product Description

Samsung 23.8Inch Desktop LCD Monitor Module

The LTM238HL061 is a 23.8-inch diagonal a-Si TFT-LCD display panel from Samsung Display Co., Ltd., featuring 1920×1080 Full HD resolution, 250 cd/m² brightness, and a 1000:1 contrast ratio. This LCD module includes an integrated WLED backlight system and is designed for desktop monitor applications.

Key Specifications

Model Number	LTM238HL061
Panel Size	23.8-inch Diagonal
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920×1080 (FHD), 92 PPI
Brightness	250 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (CR≥10)
Response Time	14ms (Typical, G to G)
Color Support	16.7 Million Colors, 72% NTSC
Interface	LVDS (2 ch, 8-bit), 30-pin Connector
Backlight	WLED [14S4P], 40,000 hours
Power Supply	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	2.15 kg (Maximum)

Panel Features

This display module features 3-side borderless design, matte anti-glare treatment with hard coating (3H), PLS technology with normally black operating mode, and symmetrical viewing angles. The active display area measures 527.04mm × 296.46mm with overall dimensions of 535.04mm × 312.96mm × 12.7mm.

Product Images

Important Note: This model entered mass production in Q1 2018 and is currently discontinued. Specifications and production status are provided for reference only. For current production status and latest specifications, please contact Samsung Display Co., Ltd. or their authorized agents.
