24" 1920x1080 FHD LCD Monitor with 30PIN Connector for Desktop Monitor Applications

Name: 24" 1920x1080 FHD LCD Monitor with 30PIN Connector for Desktop Monitor Applications
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M240HTN01.2
Price: 30.00 USD
Availability: InStock

Brand Name:	AUO
Model Number:	M240HTN01.2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080PIXELS

Brightness:

250cd

Connector:

30PIN

Contrast Ratio:

1000:1

Working Time:

30k Hours

Input Voltage:

5.0V

Packaging Details:

Industrial packing

Highlight:

91PPI Desktop LCD Monitor

Glass Oled Desktop LCD Monitor

M240HTN01.2 Lcd Screen

Product Description

91PPI Desktop LCD Monitor Glass OLED AUO 24" 30 PIN 5.0V M240HTN01.2

High-performance 24-inch desktop monitor LCD panel featuring FHD resolution and advanced display technology for professional applications.

Product Overview

The M240HTN01.2 is a 24.0" diagonal a-Si TFT-LCD display panel from AU Optronics Corp., featuring an integrated WLED backlight system. This panel operates within a temperature range of 0~50°C and is designed for desktop monitor applications with TCO 6.0 compliance certification.

Key Features

24-inch diagonal display with 1920*1080 FHD resolution
91 PPI pixel density for sharp image quality
250 cd/m² brightness with 1000:1 contrast ratio
WLED backlight system with 30,000-hour lifespan
LVDS signal interface with 30-pin connector
5.0V input voltage operation
Matte surface with anti-glare hard coating (3H)
TCO 6.0 compliance for environmental standards

Technical Specifications

Panel Brand	AU Optronics Corp. (AUO)
Panel Model	M240HTN01.2
Panel Size	24.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)*1080 (FHD), 91 PPI
Display Area	531.36mm * 298.89mm
Brightness	250 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	85/85/80/80 (CR≥10)
Response Time	3.5/1.5 ms (Tr/Td)
Display Colors	16.7 million, 72% NTSC
Signal Interface	LVDS (2 ch, 8-bit), 30-pin connector
Input Voltage	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	1.89 kg (Typical)

Note: Production status information is for reference only. For integration into products, contact AU Optronics or their authorized agents for the latest production and specification details.
