Innolux 28Inch 3840*2160 Resolution LCD Monitor with 300cd/m² Brightness and WLED Backlight

Name: Innolux 28Inch 3840*2160 Resolution LCD Monitor with 300cd/m² Brightness and WLED Backlight
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M280DGJ-L30
Price: 30.00 USD
Availability: InStock

Brand Name:	innolux
Model Number:	M280DGJ-L30
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

Taiwan

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 3840*2160

Brightness:

300cd

Connector:

30pin

Contrast Ratio:

1600:1

Working Life:

30K Hours

Packaging Details:

Industrial packing

Highlight:

3840*2160 Laptop Lcd Monitor

Innolux 28Inch Laptop Lcd Monitor

M280DGJ-L30

Product Description

Innolux 28-Inch UHD LCD Monitor M280DGJ-L30

3840*2160 pixels Innolux 28-inch laptop LCD monitor M280DGJ-L30 with 300 cd/m² brightness, 1000:1 contrast ratio, 51-pin interface, 12V power supply, and 30,000 hours WLED backlight lifespan.

Product Overview

The Innolux M280DGJ-L30 is a 28.0-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This professional-grade monitor features an operating temperature range of 0~50°C and storage temperature range of -20~60°C.

Key Features

WLED Backlight with 30,000 hours lifespan
Reverse I/F and 10-bit color depth
Matte finish with anti-glare treatment
G-Sync / FreeSync compatibility
Energy Star 7.0 Compliance
Designed for desktop monitor applications

Technical Specifications

Brand	Innolux	Model	M280DGJ-L30
Diagonal Size	28.0 inch	Type	a-Si TFT-LCD, LCM
Pixel Format	3840(RGB)*2160 [UHD] 157PPI	Configuration	RGB Vertical Stripe
Active Area	620.93(H)*341.28(V) mm	Outline Dimensions	648.9(H)369.3(V)20.85(D) mm
Luminance	300 cd/m² (Typ.)	Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	1000:1 (Typ.)	Response Time	1.5/3.5 (Typ.)(Tr/Td)
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Support Color	1.07B 72% NTSC	Light Source	WLED [4 strings], 30K hours, W/O Driver
Interface Type	V-by-One 8 lane 51 pins Connector	Power Supply	12.0V (Typ.)

Environmental Specifications

Operating Temperature: 0~50°C | Storage Temperature: -20~60°C

Product Images
