| Brand Name: | innolux |
| Model Number: | M280DGJ-L30 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
3840*2160 Pixels innolux 28Inch laptop lcd monitor M280DGJ-L30 300 cd/m² (Typ.) 1000:1 51pin 12V 30k hours WLED
Innolux Corporation (hereafter called Innolux) M280DGJ-L30 is a 28.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: WLED Backlight, Reverse I/F, 10 bit, Matte, G-Sync / FreeSync , Energy Star 7.0 Compliance, Gsync/Freesync. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q3, 2013, Now this model is in production. We inputted this model's specification on Aug 15 2013 for the first time, and the latest update on Jul 7 2020. If you want to embed M280DGJ-L30 LCM in your future product,einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The M280DGJ-L30 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
| Brand |
|---|
| Diagonal Size |
| Pixel Format |
| Active Area |
| Bezel Area |
| Luminance |
| View Direction |
| Viewing Angle |
| Support Color |
| Weight |
| Frame Rate |
| Innolux |
| 28.0 inch |
| 3840(RGB)×2160 [UHD] 157PPI |
| 620.93(H)×341.28(V) mm |
| 626.93(H)×347.28(V) mm |
| 300 cd/m² (Typ.) |
| 6 o'clock |
| 85/85/80/80 (Typ.)(CR≥10) |
| 1.07B 72% NTSC |
| 2.91/3.10Kgs (Typ./Max.) |
| 60Hz |
| Model |
| Type |
| Configuration |
| Outline Dim. |
| Treatment |
| Contrast Ratio |
| Response Time |
| Operating Mode |
| Light Source |
| Designed For |
| Touch Panel |
| M280DGJ-L30 |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| 648.9(H)×369.3(V) ×20.85(D) mm |
| Antiglare (Haze 25%), Hard coating (3H) |
| 1000:1 (Typ.) (TM) |
| 1.5/3.5 (Typ.)(Tr/Td) |
| TN, Normally White, Transmissive |
| WLED [4 strings] , 30K hours , W/O Driver |
| Without |
| Interface Type | V-by-One 8 lane 51 pins Connector |
|---|---|
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
|
|
