Sharp 19-inch LCD Monitor with 470cd/m² Brightness 1280x1024 Resolution and WLED Backlight

Name: Sharp 19-inch LCD Monitor with 470cd/m² Brightness 1280x1024 Resolution and WLED Backlight
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LQ190E1LW61
Price: 30.00 USD
Availability: InStock

Brand Name:	Sharp
Model Number:	LQ190E1LW61
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1280*1024

Brightness:

470cd

Connector:

30PIN

Contrast Ratio:

1500:1

Working Time:

50k Hours

Input Voltage:

5.0 V

Panel Weight:

1.3kg

Packaging Details:

Industrial packing

Highlight:

1280x1024 Sharp Lcd Monitor

470cd/m² Sharp Lcd Monitor

LQ190E1LW61

Product Description

470cd/m² 19" 1280x1024 Sharp LCD Monitor SXGA 86PPI LQ190E1LW61

Sharp 19-inch Gaming LCD Display LQ190E1LW61 featuring 1280×1024 SXGA resolution, 86PPI pixel density, 30-pin connector, and 470 cd/m² brightness. Brand new condition.

Technical Specifications

Panel Brand	Sharp
Panel Model	LQ190E1LW61
Panel Size	19.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)×1024, SXGA, 86PPI
Pixel Format	RGB Vertical Stripe
Display Area	376.32(W)×301.056(H) mm
Outline Size	396(W)×323.5(H)×12(D) mm
Surface Treatment	Antiglare (Haze 3%), Hard coating (2H)
Brightness	470 cd/m² (Typical)
Contrast Ratio	1500:1 (Typical)
Viewing Angle	85/85/85/85 (Typical, CR≥10)
Display Mode	ASV, Normally Black, Transmissive
Best View	Symmetry
Response Time	35ms (Typical, Tr+Td)
Display Colors	16.7M, 90% NTSC
Backlight	WLED, 50K hours lifespan, With LED Driver
Refresh Rate	60Hz
Touch Screen	Without
Panel Weight	1.30 kg (Maximum)
Signal Interface	LVDS (2 ch, 8-bit), 30-pin Connector
Input Voltage	5.0V (Typical)
Operating Temperature	0°C to 60°C
Storage Temperature	-25°C to 60°C

Key Features

Wide Color Gamut with DCI-P3 and sRGB support
WLED Backlight with 50,000+ hours lifespan
Integrated LED Driver
Matte finish surface
Upside interface configuration

Application

Production Information: This Sharp LQ190E1LW61 model entered mass production in Q2 2014 and is currently in active production. For the latest specifications and production details for integration into your products, we strongly recommend contacting Sharp or their authorized distributors directly.
