BOE EV101WXM-N80 10.1 Inch LCD Panel with 1280*800 Pixels and 400 cd/m² Brightness

Name: BOE EV101WXM-N80 10.1 Inch LCD Panel with 1280*800 Pixels and 400 cd/m² Brightness
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: EV101WXM-N80
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	EV101WXM-N80
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

Black Or Silver,16.7M Color For Display

Model:

WLED,LCD

Style:

Wide Screen High Resolution 1280*800pixels

Brightness:

400 Cd/m²

Working Life:

30k Hours

Display Size:

10.1inch

Connector:

20pin

Packaging Details:

Industrial packing

Highlight:

400cd/m² Lcd Touch Panel

10.1 Inch Touch Lcd Panel

Product Description

EV101WXM-N80 1280×800 400cd/m² 10.1 Inch Touch LCD Panel

Original brand new BOE 10.1 inch LCD model EV101WXM-N80 with 1280×800 pixels resolution and 400 cd/m² brightness

Product Specifications

Brand	BOE
Model	EV101WXM-N80
Diagonal Size	10.1 inch
Type	a-Si TFT-LCD, LCM
Pixel Format	1280(RGB)×800 [WXGA]
Configuration	RGB Vertical Stripe
Active Area	216.96(H)×135.6(V) mm
Outline Dimensions	233.2(H)×152.9(V)×10.4(D) mm
Bezel Area	219.4(H)×138.0(V) mm
Luminance	400 cd/m² (Typical)
Contrast Ratio	900:1 (Typical) (TM)
View Direction	Symmetry
Response Time	30 ms (Typical)(Tr+Td)
Viewing Angle	85/85/85/85 (Typical)(CR≥10)
Operating Mode	ADS, Normally Black, Transmissive
Support Color	16.7M 48% NTSC
Light Source	WLED, 30K hours, Without Driver
Weight	505g (Typical)
Frame Rate	60Hz
Touch Panel	Without
Interface Type	20 pins LVDS (1 ch, 8-bit), Connector
Power Supply	3.3V (Typical)
Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C

Product Images
