| Brand Name: | LG |
| Model Number: | LM290WW2-SSD1 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Panel Brand | LG Display | Panel Model | LM290WW2-SSD1 |
|---|---|---|---|
| Panel Size | 29.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 2560(RGB)×1080 , CSHD | Pixel Format | RGB Vertical Stripe |
| Display Area | 672.768(W)×283.824(H) mm | Bezel Opening | - |
| Outline Size | 693.6(W)×308.9(H) ×17(D) mm | Surface | Antiglare, Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry | Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 99% sRGB | Lamp Type | 18S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz | Touch Screen | Without |
| Panel Weight | 3.11/3.265Kgs (Typ./Max.) | Application |
|
| Signal Interface | LVDS (4 ch, 8-bit) , 92 pins , Connector | ||
| Input Voltage | 10.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
LM290WW2-SSD1 (Alias: LM290WW2 (SS)(D1)) is a 29.0" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: sRGB, 3-side boderless, WLED Backlight, Reverse I/F, Matte , sRGB, 3-side borderless. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Industrial, Medical Imaging etc. According to the information stored in einklcd this model mass production on Q2, 2016, Now this model is discontinued. We inputted this model's specification on Aug 1 2018 for the first time, and the latest update on Aug 20 2019. If you want to embed the LCM in your future product, einlcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LM290WW2-SSD1. The production status marked on einlkcd.com is for reference only and should not be used as the basis for the user's decision making.
|
|
