Innolux 21.5 Inch 1920*1080 Resolution LCD Display Desktop Monitor with 30 Pin Connector

Name: Innolux 21.5 Inch 1920*1080 Resolution LCD Display Desktop Monitor with 30 Pin Connector
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M215HJJ-P02
Price: 30.00 USD
Availability: InStock

Brand Name:	Innolux
Model Number:	M215HJJ-P02
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080

Brightness:

400cd

Connector:

30PIN

Contrast Ratio:

3000:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

portable touch screen monitor

touch screen display monitor

Product Description

21.5" Innolux M215HJJ-P02 Touch Screen Desktop Monitor

21.5-inch diagonal a-Si TFT-LCD display panel from Innolux Corporation featuring 1920×1080 FHD resolution and wide viewing angle capabilities.

Panel Specifications

Panel Brand	Innolux
Panel Size	21.5"
Resolution	1920(RGB)×1080, FHD
Display Area	476.064(W)×267.786(H) mm
Outline Size	487.664(W)×279.286(H)×1.288(D) mm
Brightness	0 cd/m²
Viewing Angle	89/89/89/89 (Typ.)(CR≥20)
Best View	Symmetry
Glass Depth	0.50+0.50 mm
Display Colors	16.7M 72% (CIE1931)
Frequency	60Hz
Weight	400g (Typ.)

Technical Details

Panel Model	M215HJJ-P02
Panel Type	a-Si TFT-LCD, CELL
Pixel Format	RGB Vertical Stripe
Surface	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	3000:1 (Typ.) (TM)
Display Mode	MVA, Normally Black, Transmissive
Response Time	20/5 (Typ.)(Tr/Td)
Transmissivity	4.46% (Typ.)(with Polarizer)
Lamp Type	No B/L
Touch Screen	Without
Signal Interface	LVDS (2 ch, 8-bit), 30 pins, Connector
Input Voltage	5.0V (Typ.)
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C

Key Features

High Color Gamut for vibrant image reproduction
Antiglare Surface with hard coating (3H) for durability
Wide Viewing Angle (89/89/89/89) for consistent visibility
Landscape orientation with wide aspect ratio
MVA technology with normally black display mode

Product Images

This M215HJJ-P02 model is recommended for desktop monitor applications. Mass production began in Q4 2014 and the model remains in production.

Note: Production status information is for reference only. For the latest production and specification details, please contact Innolux or their authorized agents directly.
