| Brand Name: | Innolux |
| Model Number: | M215HJJ-P02 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Glass Depth |
| Display Colors |
| Frequency |
| Weight |
| Innolux |
| 21.5" |
| 1920(RGB)×1080 , FHD |
| 476.064(W)×267.786(H) mm |
| 487.664(W)×279.286(H) ×1.288(D) mm |
| 0 cd/m² |
| 89/89/89/89 (Typ.)(CR≥20) |
| Symmetry |
| 0.50+0.50 mm |
| 16.7M 72% (CIE1931) |
| 60Hz |
| 400g (Typ.) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Transmissivity |
| Lamp Type |
| Touch Screen |
| Application |
| M215HJJ-P02 |
| a-Si TFT-LCD , CELL |
| RGB Vertical Stripe |
| - |
| Antiglare (Haze 25%), Hard coating (3H) |
| 3000:1 (Typ.) (TM) |
| MVA, Normally Black, Transmissive |
| 20/5 (Typ.)(Tr/Td) |
| 4.46% (Typ.)(with Polarizer) |
| No B/L |
| Without |
|
|
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins , Connector |
|---|---|
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
M215HJJ-P02 is a 21.5" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), without backlight, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by EINKLCD in the following: High Color Gamut, Antiglare Surface, Wide Viewing Angle, Landscape type, Wide Aspect Ratio . Based on its features, Einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production. We inputted this model's specification on Nov 10 2014 for the first time, and the latest update on Sep 7 2017. If you want to embed the CELL in your future product, einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of M215HJJ-P02. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
|
|
