BOE 14" Widescreen LCD Monitor with 1920*1080 Resolution 400cd/m² Brightness and WLED Backlight

Name: BOE 14" Widescreen LCD Monitor with 1920*1080 Resolution 400cd/m² Brightness and WLED Backlight
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: NE140FHM-N61
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	NE140FHM-N61
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080

Brightness:

400cd

Connector:

Contrast Ratio:

1500:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

touch screen computer monitor

high resolution touch screen monitor

Product Description

BOE 14" Widescreen LCD Monitor Panel

Product Overview

The NE140FHM-N61 is a 14.0-inch diagonal IGZO TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integrated WLED backlight system with LED driver. This high-performance display is designed for laptop applications and offers exceptional color reproduction and viewing angles.

Technical Specifications

Panel Brand	BOE
Panel Model	NE140FHM-N61
Panel Size	14.0 inches
Panel Type	IGZO TFT-LCD, LCM
Resolution	1920*1080 (FHD)
Pixel Format	RGB Vertical Stripe
Display Area	309.312*173.988 mm
Outline Size	315.312196.12.4 mm
Surface	Antiglare, Hard coating (3H)
Brightness	400 cd/m² (Typical)
Contrast Ratio	1500:1 (Typical)
Viewing Angle	85/85/85/85 (CR≥10)
Display Mode	ADS, Normally Black, Transmissive
Response Time	35 ms (Typical)
Display Colors	16.7M, 72% (CIE1931)
Backlight	10S6P WLED, 15K hours
Refresh Rate	60Hz
Signal Interface	eDP (2 Lanes), 30 pins, Connector
Input Voltage	3.3V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Key Features

High Color Gamut for vibrant, accurate color reproduction
Antiglare Surface with hard coating (3H) for reduced reflections
Wide Viewing Angle (85/85/85/85) for consistent image quality
Landscape orientation design
White LED Backlight with extended 15,000-hour lifespan
eDP 1.4 Signal Interface with reverse position

Application & Production Information

This display panel is recommended for laptop applications and similar computing devices. Mass production began in Q4 2018, and the model remains in active production.

Important Notice: For integration of the NE140FHM-N61 LCM into your products, we strongly recommend contacting BOE or their authorized agents to obtain the latest production status and detailed specifications. The information provided here is for reference purposes only and should not be used as the sole basis for decision-making.
