Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Material: | Glass Oled | Color: | 1.07b Colors |
| Model: | WLED | Style: | Wide Screen High Resolution 1920*1080 |
| Brightness: | 300cd | Connector: | 30pin |
| Contrast Ratio: | 700:1 | Working Life: | 15K Hours |
| High Light: | touch screen computer monitor,high resolution touch screen monitor |
||
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Display Colors |
| Frequency |
| Shape Style |
| Innolux |
| 17.3" |
| 1920(RGB)×1080 , FHD |
| 381.888(W)×214.812(H) mm |
| 399.5(W)×250.51(H) ×4(D) mm |
| 300 cd/m² (Typ.) |
| 89/89/89/89 (Typ.)(CR≥10) |
| Symmetry |
| 262K 72% (CIE1931) |
| 60Hz |
| Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Lamp Type |
| Touch Screen |
| Application |
| N173HCE-E31 (CMN1738) |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| - |
| Antiglare, Hard coating (3H) |
| 700:1 (Typ.) (TM) |
| AAS, Normally Black, Transmissive |
| 14/11 (Typ.)(Tr/Td) |
| WLED , 15K hours , With LED Driver |
| Without |
|
|
| Signal Interface | eDP (2 Lanes) , 30 pins , Connector |
|---|---|
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
It's 300cd/m2 Innolux 17.3nch lcd MODEL for monitor ,Desktop screen.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
