HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels

HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels
HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels

Large Image :  HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels

Product Details:
Place of Origin: CHINA
Brand Name: BOE
Certification: Rohs,CE,FCC
Model Number: HT150X02-100
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week

HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels

Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 16.7m Colors
Model: WLED Style: Wide Screen High Resolution 1024*768
Brightness: 250cd Connector: 20
Contrast Ratio: 500:1 Working Time: 50k Hours
High Light:

touch screen computer monitor

,

high resolution touch screen monitor

  • Brand
    BOE
  • Model
    HT150X02-100
  • Diagonal Size
    15.0 inch
  • Type
    a-Si TFT-LCD, LCM
  • Pixel Format
    1024(RGB)×768 [XGA]
  • Configuration
    RGB Vertical Stripe
  • Active Area
    304.128(H)×228.096(V) mm
  • Outline Dim.
    326.5(H)×253.5(V) ×11.9(D) mm
  • Bezel Area
    307.4(H)×231.3(V) mm
  • Treatment
    Antiglare (Haze 25%), Hard coating (3H)
  • Luminance
    250 cd/m² (Typ.)
  • Contrast Ratio
    500:1 (Typ.) (TM)
  • View Direction
    -
  • Response Time
    2/6 (Typ.)(Tr/Td)
  • Viewing Angle
    75/75/70/60 (Typ.)(CR≥10)
  • Operating Mode
    TN, Normally White, Transmissive
  • Support Color
    16.2M 60% (CIE1931)
  • Light Source
    CCFL [2 pcs] , 50K hours , W/O Driver
  • Weight
    1.20Kgs (Max.)
  • Designed For
    HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels 0 HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels 1
  • Frame Rate
    60Hz
  • Touch Panel
    Without
  • Interface Type
  • 20 pins LVDS (1 ch, 8-bit) , Connector
  • Power Supply
  • 3.3V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
  • HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels 2HT150X02-100 High Resolution Touch Screen Monitor 250CD/M2 BOE 15" LCD Model 1024*768 Pixels 3



HT150X02-100 is a 15.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcdin the following: Antiglare Surface, Landscape type, Lamp life ≥ 50K hours, Normal Signal Interface Position . Based on its features, einklcd recommend that this model be applied to Industrial, Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q2, 2006 and last shippment on Q4, 2013, Now this model is discontinued. We inputted this model's specification on Jan 5 2012 for the first time, and the latest update on Dec 23 2016. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of HT150X02-100. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.



                         All our LCD LED screen monitor module panel products will be full test one by one before sending .
