250CD/M2 20 Pin Touch Screen Computer Monitor TIANMA 15" LCD Model TMS150XG1-10TB

Brand Name: TIANMA
Model Number: TMS150XG1-10TB
MOQ: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Payment Terms: T/T,W, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
Rohs,CE,FCC
Quality:
Brand New Original
Package:
Original Industrial Packing
Material:
Glass Oled
Color:
16.7m Colors
Model:
WLED
Style:
Wide Screen High Resolution 1024*768
Brightness:
250cd
Connector:
20
Contrast Ratio:
600:1
Working Time:
40k Hours
Supply Ability:
3000pcs per week
Highlight:

touch screen computer monitor

,

high resolution touch screen monitor

Product Description
  • Panel Brand
    AVIC
  • Panel Model
    TMS150XG1-10TB
  • Panel Size
    15.0"
  • Panel Type
    a-Si TFT-LCD, LCM
  • Resolution
    1024(RGB)×768 , XGA
  • Pixel Format
    RGB Vertical Stripe
  • Display Area
    304.128(W)×228.096(H) mm
  • Bezel Opening
    307.4(W)×231.3(H) mm
  • Outline Size
    326.5(W)×253.5(H) ×12(D) mm
  • Surface
    Antiglare
  • Brightness
    250 cd/m² (Typ.)
  • Contrast Ratio
    600:1 (Typ.) (TM)
  • Viewing Angle
    80/80/80/80 (Typ.)(CR≥10)
  • Display Mode
    TN, Normally White, Transmissive
  • Best View on
    -
  • Response Time
    2/6 (Typ.)(Tr/Td)
  • Display Colors
    16.7M 60% (CIE1931)
  • Lamp Type
    2 pcs CCFL , 40K hours , Without Driver
  • Frequency
    60Hz
  • Touch Screen
    Without
  • Panel Weight
    1.00Kgs (Typ.)
  • Application
    250CD/M2 20 Pin Touch Screen Computer Monitor TIANMA 15" LCD Model TMS150XG1-10TB 0
  • Signal Interface
  • LVDS (1 ch, 8-bit) , 20 pins , Connector
  • Input Voltage
  • 3.3V (Typ.)
  • Environment
  • Operating Temp.: 0 ~ 55 °C ; Storage Temp.: -20 ~ 60 °C

250CD/M2 20 Pin Touch Screen Computer Monitor TIANMA 15" LCD Model TMS150XG1-10TB 1250CD/M2 20 Pin Touch Screen Computer Monitor TIANMA 15" LCD Model TMS150XG1-10TB 2250CD/M2 20 Pin Touch Screen Computer Monitor TIANMA 15" LCD Model TMS150XG1-10TB 3



The TMS150XG1-10TB is a 15.0 inch diagonal a-Si TFT-LCD display panel product from Shanghai AVIC Optoelectronics Co. Ltd. (hereafter called AVIC), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 55°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Panelook in the following: Antiglare Surface, Wide Viewing Angle, Landscape type , TC0’5.0 Compliance. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q2, 2010 and last shippment on Q3, 2014, Now this model is discontinued. We inputted this model's specification on Nov 8 2012 for the first time, and the latest update on Sep 3 2014. If you want to embed TMS150XG1-10TB LCM in your future product, einklcd strongly recommend that you should contact with AVIC or it's agent to learn lateast production and specification detail. The TMS150XG1-10TB production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.



                         All our LCD LED screen monitor module panel products will be full test one by one before sending .
