| Brand Name: | BOE |
| Model Number: | MT185WHM-N20 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Brand
BOE
Model
MT185WHM-N20
Diagonal Size
18.5 inch
Type
a-Si TFT-LCD, LCM
Pixel Format
1366(RGB)×768 [WXGA]
Configuration
RGB Vertical Stripe
Active Area
409.8(H)×230.4(V) mm
Outline Dim.
430.4(H)×254.6(V) ×11.4(D) mm
Bezel Area
413.4(H)×234.0(V) mm
Treatment
Antiglare (Haze 25%), Hard coating (3H)
Luminance
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
View Direction
6 o'clock
Response Time
1.5/3.5 (Typ.)(Tr/Td)
Viewing Angle
85/85/80/80 (Typ.)(CR＞10)
Operating Mode
TN, Normally White, Transmissive
Support Color
16.7M 72% (CIE1931)
Light Source
WLED , 30K hours , W/O Driver
Weight
1.31Kgs (Typ.)
Designed For
Frame Rate
60Hz
Touch Panel
Without
Interface Type
30 pins LVDS (1 ch, 8-bit) , Connector
Power Supply
5.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
MT185WHM-N20 is a 18.5" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: High Color Gamut, Antiglare Surface, Wide Viewing Angle, Landscape type, White LED Backlight, Wide Aspect Ratio, Normal Signal Interface Position , ES 7.0 Compliant. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q2, 2015, Now this model is in production. We inputted this model's specification on Sep 19 2015 for the first time, and the latest update on May 17 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of MT185WHM-N20. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
