| Brand Name: | LG |
| Model Number: | LM300WQ6-SLA1 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Brand
LG Display
Model
LM300WQ6-SLA1
Diagonal Size
30.0 inch
Type
a-Si TFT-LCD, LCM
Pixel Format
2560(RGB)×1600 [WQXGA]
Configuration
RGB Vertical Stripe
Active Area
641.28(H)×400.8(V) mm
Outline Dim.
677.3(H)×436.8(V) ×18.5(D) mm
Bezel Area
646.3(H)×405.8(V) mm
Treatment
Antiglare, Hard coating (3H)
Luminance
350 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
7/7 (Typ.)(Tr/Td); 6 (Typ.)(G to G)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
AH-IPS, Normally Black, Transmissive
Support Color
1.07B 104% (CIE1931)
Light Source
GB-r LED , 30K hours , W/O Driver
Weight
4.15/4.36Kgs (Typ./Max.)
Designed For
Frame Rate
60Hz
Touch Panel
Without
Interface Type
92 pins LVDS (4 ch, 10-bit) , Connector
Power Supply
12.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °
LM300WQ6-SLA1 (Alias: LM300WQ6 (SL)(A1)) is a 30.0" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral GB-r LED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C .Einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q4, 2012, Now this model is in production. We inputted this model's specification on Feb 1 2013 for the first time, and the latest update on Dec 1 2017. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LM300WQ6-SLA1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
