24'' WUXGA LCD Monitor with 250cd/m² Brightness and 30PIN LVDS Interface for High Resolution Display

Name: 24'' WUXGA LCD Monitor with 250cd/m² Brightness and 30PIN LVDS Interface for High Resolution Display
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: MV240WUM-N30
Price: 30.00 USD
Availability: InStock

Brand Name:	boe
Model Number:	MV240WUM-N30
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

KOREA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1200

Brightness:

250cd

Connector:

30pin

Contrast Ratio:

1000:1

Working Life:

30K Hours

Packaging Details:

Industrial packing

Highlight:

touch screen computer monitor

high resolution touch screen monitor

Product Description

30 PIN Full HD Touch Screen Monitor BOE 24'' 1920*1200 Pixels 250cd/m² MV240WUM-N30

Product Overview

High-performance 24-inch BOE LCD panel module featuring WUXGA resolution and industrial-grade specifications. This MV240WUM-N30 model delivers exceptional display quality for professional applications.

Technical Specifications

Panel Brand	BOE
Panel Model	MV240WUM-N30
Panel Size	24.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)*1200 (WUXGA)
Pixel Format	RGB Vertical Stripe
Display Area	518.4(W)*324(H) mm
Outline Size	546.4(W)*350(H) mm
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Brightness	250 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Display Mode	ADS, Normally Black, Transmissive
Response Time	14ms (Typical, G to G)
Display Colors	16.7M, 72% (CIE1931)
Backlight Type	WLED, 30K hours lifespan
Refresh Rate	60Hz
Touch Screen	Without
Signal Interface	LVDS (2 ch, 8-bit), 30 pins, Connector
Input Voltage	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Key Features

Full HD WUXGA resolution (1920*1200 pixels)
High brightness 250 cd/m² display
Wide 89-degree viewing angles
Anti-glare surface with 3H hard coating
30-pin LVDS interface compatibility
WLED backlight with 30,000-hour lifespan
Industrial operating temperature range

Applications

Ideal for television displays, computer monitors, digital signage, TV wall installations, and desktop computer systems requiring high-quality visual performance.

Quality Assurance: All LCD LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
