Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Material: | Glass Oled | Color: | 16.7M Colors |
| Model: | WLED | Style: | Wide Screen High Resolution 1680*1050 |
| Brightness: | 250cd | Connector: | 30pin |
| Contrast Ratio: | 1000:1 | Working Life: | 40K Hours |
| High Light: | touch screen computer monitor,high resolution touch screen monitor |
||
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Display Colors |
| Frequency |
| Weight |
| BOE |
| 22.0" |
| 1680(RGB)×1050 , WSXGA+ |
| 473.76(W)×296.1(H) mm |
| 493.7(W)×320.1(H) ×10.7(D) mm |
| 250 cd/m² (Typ.) |
| 85/85/80/80 (Typ.)(CR≥10) |
| 6 o'clock |
| 16.7M 72% (CIE1931) |
| 60Hz |
| 1.83Kgs (Typ.) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Lamp Type |
| Touch Screen |
| Application |
| MT220WPM-N10 |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| 477.7(W)×300.1(H) mm |
| Antiglare (Haze 25%), Hard coating (3H) |
| 1000:1 (Typ.) (TM) |
| TN, Normally White, Transmissive |
| 1.5/3.5 (Typ.)(Tr/Td) |
| 3 strings WLED , 40K hours , Without Driver |
| Without |
|
|
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins , Connector |
|---|---|
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
It's 250cd/m2 22inch BOE lcd MODEL for TV and monitor ,TV wall lcd,Destktop computer
All our LCD LED screen monitor module panel products will be full test one by one before sending .
