| Brand Name: | BOE |
| Model Number: | HR236WU1-300 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Panel Brand
BOE
Panel Model
HR236WU1-300
Panel Size
23.6"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1080 , FHD
Pixel Format
RGB Vertical Stripe
Display Area
521.28(W)×293.22(H) mm
Bezel Opening
525.22(W)×297.22(H) mm
Outline Size
544.8(W)×320.5(H) ×10.5(D) mm
Surface
Antiglare (Haze 25%), Hard coating (3H)
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
ADS, Normally Black, Transmissive
Best View on
Symmetry
Response Time
14 (Typ.)(G to G)
Display Colors
16.7M (sRGB)
Lamp Type
4 strings WLED , 30K hours , Without Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
2.20Kgs (Typ.)
Application
Signal Interface
LVDS (2 ch, 8-bit) , 30 pins , Connector
Input Voltage
5.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
