BOE 14 Inch 1920*1080 Pixels 30 Pin IPS LCD Monitor with Full HD TFT-LCD Screen

Name: BOE 14 Inch 1920*1080 Pixels 30 Pin IPS LCD Monitor with Full HD TFT-LCD Screen
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: NV140FHM-N47
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	NV140FHM-N47
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1920*1080

Style:

30PIN IPS

Brightness:

300 CD/M2

Color:

262K

Contrast Ratio:

700 :1

Packaging Details:

Industrial packing

Highlight:

smart touch screen monitor

high resolution touch screen monitor

Product Description

30 Pin IPS Full HD Touch Screen Monitor BOE 14 Inch 1920*1080 Pixels NV140FHM-N47

Product Overview

High-quality 14-inch IPS LCD display module featuring Full HD resolution and advanced display technology for industrial and commercial applications.

Technical Specifications

Manufacturer	BOE
Model Name	NV140FHM-N47 (BOE06EE)
Screen Size	14.0 inch
Screen Type	LCM, a-Si TFT-LCD
Resolution	1920(RGB) * 1080 (FHD)
Pixel Arrangement	RGB Vertical Stripe
Active Area	309.31 * 173.99 mm (H*V)
Outline Dimensions	320.4 * 194.65 * 5.25 mm (HVD)
Surface Treatment	Antiglare, Hard coating (3H)
Brightness	300 cd/m² (Typical)
Contrast Ratio	700:1 (Typical)
Viewing Angle	85/85/85/85 (Typical, CR ≥10)
Response Time	30 ms (Typical, Tr+Td)
Viewing Mode	Symmetry
Operation Mode	ADS, Normally Black, Transmissive
Color Depth	262K, 72% (CIE1931)
Backlight System	10S4P WLED, 15K hours, With LED Driver
Outline Shape	Slim (PCBA Bent, Depth ≤3.0mm)
Refresh Rate	60Hz
Touchscreen	Without
Signal Interface	eDP (2 Lanes), Connector, 30 pins
Operating Voltage	3.3V (Typical)
Temperature Range	Storage: -20°C to 60°C, Operating: 0°C to 50°C

Quality Assurance: All original products undergo comprehensive testing before shipment to ensure optimal performance and reliability.

Detailed specification documents available upon request. Please contact us for complete technical documentation.
