| Brand Name: | CHIMEI INNOLUX |
| Model Number: | M215HNE-L30 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Brand
Innolux
Model
M215HNE-L30 Rev.C3
Diagonal Size
21.5 inch
Type
a-Si TFT-LCD, LCM
Pixel Format
1920(RGB)×1080 [FHD]
Configuration
RGB Vertical Stripe
Active Area
476.064(H)×267.786(V) mm
Outline Dim.
495.6(H)×292.2(V) ×12(D) mm
Bezel Area
479.84(H)×271.3(V) mm
Treatment
Antiglare, Hard coating (3H)
Luminance
250 cd/m² (Typ.)
Contrast Ratio
3000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
15/5 (Typ.)(Tr/Td)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
Super MVA, Normally Black, Transmissive
Support Color
16.7M 72% (CIE1931)
Light Source
WLED [4 strings] , 40K hours , W/O Driver
Weight
1.80/1.85Kgs (Typ./Max.)
Designed For
Frame Rate
60Hz
Touch Panel
Without
Interface Type
30 pins LVDS (2 ch, 8-bit) , Connector
Power Supply
5.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
