21.5 Inch LM215WF3 SLK1 LCD Monitor with 1920*1080pixels Resolution and 30PIN LVDS Interface for Desktop Replacement

Name: 21.5 Inch LM215WF3 SLK1 LCD Monitor with 1920*1080pixels Resolution and 30PIN LVDS Interface for Desktop Replacement
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LM215WF3-SLK1
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LM215WF3-SLK1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

250CCD/M2

Resolution:

1920*1080pixels

Contrast Ratio:

1000:1

Color:

16.7M

Working Life:

30K Hours

Connector:

30P

Packaging Details:

Industrial packing

Highlight:

touch screen desktop monitor

touch screen display monitor

Product Description

22 Inch LM215WF3 SLK1 LCD Touch Screen Monitor

Brand new 22-inch LG-Philips LCD monitor LM215WF3-SLK1 with high resolution 1920×1080 pixels and 30-pin interface for desktop LCD replacement applications.

Key Specifications

Brand	LG Display
Model	LM215WF3-SLK1
Diagonal Size	21.5 inch
Display Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080 [FHD]
Pixel Configuration	RGB Vertical Stripe
Active Area	476.064(H)×267.786(V) mm
Outline Dimensions	497.6(H)×292.2(V)×11(D) mm
Bezel Area	479.8(H)×271.3(V) mm
Surface Treatment	Antiglare, Hard coating (3H)
Brightness	250 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Response Time	14ms (Typical, G to G)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Operating Mode	IPS, Normally Black, Transmissive
Color Support	16.7M 72% (CIE1931)
Backlight	WLED [16S2P], 30K hours, Without Driver
Weight	1.92/2.02 kg (Typical/Maximum)

Operating Specifications

Frame Rate	60Hz
Touch Panel	Without
Interface Type	30 pins LVDS (2 ch, 8-bit), Connector
Power Supply	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Product Images

Quality Assurance

All original products undergo comprehensive testing before shipment
Detailed specification documents available upon request via email

Contact our technical support team for complete datasheets and integration assistance.
