Innolux 15.61 Inch LCD Monitor with 1920*1080pixels Resolution 250 cd/m² Brightness and 30Pin LVDS Interface

Name: Innolux 15.61 Inch LCD Monitor with 1920*1080pixels Resolution 250 cd/m² Brightness and 30Pin LVDS Interface
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M236HJJ-L31
Price: 30.00 USD
Availability: InStock

Brand Name:	Innolux
Model Number:	M236HJJ-L31
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1920*1080pixels

Style:

WLED 30P

Brightness:

250 CCD M2

Color:

16.7M

Contrast Ratio:

3000 :1

Working Life:

40K Hours

Packaging Details:

Industrial packing

Highlight:

touch screen desktop monitor

portable touch screen monitor

Product Description

High Resolution LCD Touch Screen Monitor Innolux 15.61 Inch Size M236HJJ L31

Innolux 15.61 inch LCD display M236HJJ-L31 monitor with 1920×1080 pixels resolution, 250 cd/m² brightness, and 30-pin interface replacement.

Technical Specifications

Brand	Innolux
Model	M236HJJ-L31
Diagonal Size	23.6 inch
Type	a-Si TFT-LCD, LCM
Pixel Format	1920(RGB) × 1080 [FHD]
Configuration	RGB Vertical Stripe
Active Area	521.28(H) × 293.22(V) mm
Outline Dimensions	544.8(H) × 320.5(V) × 11.5(D) mm
Bezel Area	525.22(H) × 297.22(V) mm
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	250 cd/m² (Typ.)
Contrast Ratio	3000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	20 ms (Typ.)(G to G)
Viewing Angle	89/89/89/89 (Typ.)(CR ≥10)
Operating Mode	Super MVA, Normally Black, Transmissive
Support Color	16.7M 72% (CIE1931)
Light Source	WLED [4 strings], 40K hours, Without Driver
Weight	2.31 ± 0.11 kg
Frame Rate	60Hz
Touch Panel	Without
Interface Type	30 pins LVDS (2 ch, 8-bit), Connector
Power Supply	5.0V (Typ.)
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C

Product Images

All products will be sent to customer after inspection one by one to ensure quality standards.
