| Brand Name: | INNOLUX |
| Model Number: | M220ZGE-L20 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Innolux 22 Inch LCD Panel M220ZGE-L20 Notebook LCD Display lcd PC monitor 1680*1050pixels 250CCD/M2 16.7M color 30P
Panel Brand
Chimei Innolux
Panel Model
M220ZGE-L20
Panel Size
22.0 inch
Panel Type
a-Si TFT-LCD, LCM
Resolution
1680(RGB)×1050 , WSXGA+
Pixel Format
RGB Vertical Stripe
Display Area
473.76(W)×296.1(H) mm
Bezel Opening
477.7(W)×300.1(H) mm
Outline Size
493.7(W)×320.1(H) mm
Surface
Antiglare (Haze 25%), Hard coating (3H)
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
85/85/80/80 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
-
Response Time
1.3/3.7 (Typ.)(Tr/Td)
Display Colors
16.7M 72% (CIE1931)
Lamp Type
12S4P WLED , 40K hours , Without Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
2.10/2.25Kgs (Typ./Max.)
Application
Signal Interface
LVDS (2 ch, 8-bit) , 30 pins , Connector
Input Voltage
5.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
|
|
