Innolux 22 Inch LCD Monitor with 1680x1050 Pixels Resolution and 250 cd/m² Brightness for Widescreen Display

Name: Innolux 22 Inch LCD Monitor with 1680x1050 Pixels Resolution and 250 cd/m² Brightness for Widescreen Display
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: M220ZGE-L20
Price: 30.00 USD
Availability: InStock

Brand Name:	INNOLUX
Model Number:	M220ZGE-L20
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1680*1050pixels

Style:

WLED 30P

Brightness:

250 CCD M2

Color:

16.7M

Contrast Ratio:

1000 :1

Working Life:

40K Hours

Packaging Details:

Industrial packing

Highlight:

touch screen computer monitor

smart touch screen monitor

Product Description

Innolux 22 Inch Widescreen LCD Computer Monitors M220ZGE L20 1680 * 1050 Pixels Resolution

Innolux 22 Inch LCD Panel M220ZGE-L20 Notebook LCD Display with 1680*1050 resolution, 250 cd/m² brightness, and 16.7 million colors.

Technical Specifications

Panel Brand	Chimei Innolux
Panel Model	M220ZGE-L20
Panel Size	22.0 inch
Panel Type	a-Si TFT-LCD, LCM
Resolution	1680(RGB) * 1050, WSXGA+
Pixel Format	RGB Vertical Stripe
Display Area	473.76(W) * 296.1(H) mm
Bezel Opening	477.7(W) * 300.1(H) mm
Outline Size	493.7(W) * 320.1(H) mm
Surface	Antiglare (Haze 25%), Hard coating (3H)
Brightness	250 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/80/80 (Typ.)(CR ≥10)
Display Mode	TN, Normally White, Transmissive
Response Time	1.3/3.7 (Typ.)(Tr/Td)
Display Colors	16.7M 72% (CIE1931)
Lamp Type	12S4P WLED, 40K hours, Without Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	2.10/2.25Kgs (Typ./Max.)
Signal Interface	LVDS (2 ch, 8-bit), 30 pins, Connector
Input Voltage	5.0V (Typ.)
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C

Product Features

Widescreen 22-inch LCD display with WSXGA+ resolution
High brightness and contrast ratio for clear image quality
Wide viewing angles with TN display technology
Energy-efficient WLED backlight with 40,000 hours lifespan
Antiglare surface with hard coating for durability

Quality Assurance: All products undergo individual inspection before shipment to ensure optimal performance and reliability.
