| Brand Name: | LG |
| Model Number: | LM240WU9-SLC1 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Panel Brand
LG Display
Panel Model
LM240WU9-SLC1
Panel Size
24.0"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1200 , WUXGA
Pixel Format
RGB Vertical Stripe
Display Area
518.4(W)×324(H) mm
Bezel Opening
-
Brightness
350 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
AH-IPS, Normally Black, Transmissive
Best View on
Symmetry
Response Time
6 (Typ.)(G to G)
Display Colors
1.07B (Adobe)
Lamp Type
GB-r LED , 30K hours , Without Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
-
Application
Signal Interface
LVDS (2 ch, 10-bit) , 51 pins , Connector
Input Voltage
12.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
LM240WU9-SLC1 (LM240WU9 (SL)(C1)) is a 24.0" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral GB-r LED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by us in the following: Adobe RGB, Antiglare Surface, 10 bit, Wide Viewing Angle, Landscape type, Wide Aspect Ratio, Normal Signal Interface Position , Energy Star 7.0 Compliance. Based on its features, we recommend that this model be applied to Desktop Monitor, Industrial, Medical Imaging etc. According to the information stored , this model mass production on Q2, 2017, Now this model is in production. We inputted this model's specification on Sep 19 2017 for the first time, and the latest update on Nov 22 2017. If you want to embed the LCM in your future product, we recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LM240WU9-SLC1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making. The above parameters are not from the datasheet, only as a reference, please use with caution!
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
