| Brand Name: | sharp |
| Model Number: | LQ121S1LG74 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Panel Brand | Sharp | Panel Model | LQ121S1LG74 |
|---|---|---|---|
| Panel Size | 12.1" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 800(RGB)×600 , SVGA | Pixel Format | RGB Vertical Stripe |
| Display Area | 246(W)×184.5(H) mm | Bezel Opening | - |
| Outline Size | 265(W)×205(H) ×10(D) mm | Surface | Antiglare, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) | Contrast Ratio | - |
| Viewing Angle | - | Display Mode | TN, Normally White, Transmissive |
| Best View on | - | Response Time | - |
| Display Colors | 16.2M 76% (CIE1931) | Lamp Type | WLED , With LED Driver |
| Frequency | 60Hz | Touch Screen | Without |
| Panel Weight | 550g (Max.) | Application |
|
| Signal Interface | LVDS (1 ch, 8-bit) | ||
| Environment | Operating Temp.: -10 ~ 75 °C ; Storage Temp.: -30 ~ 75 °C | ||
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
