| Brand Name: | BOE |
| Model Number: | NV140FHM-N4B |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Panel Brand
BOE
Panel Model
NV140FHM-N4B (BOE072C)
Panel Size
14.0"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1080 , FHD
Pixel Format
RGB Vertical Stripe
Display Area
309.31(W)×173.99(H) mm
Bezel Opening
-
Outline Size
316.112(W)×197.48(H) ×3(D) mm
Surface
Antiglare
Brightness
220 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (TM)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Display Mode
ADS, Normally Black, Transmissive
Best View on
Symmetry
Response Time
30 (Typ.)(Tr+Td)
Display Colors
262K 46% (CIE1931)
Lamp Type
8S4P WLED , 15K hours , With LED Driver
Frequency
60Hz
Touch Screen
Without
Shape Style
Slim (PCBA Flat, Depth ≤3.2mm)
Application
Signal Interface
eDP (2 Lanes) , 30 pins , Connector
Input Voltage
3.3V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
