| Brand Name: | LG |
| Model Number: | LP156WF4-SPU1 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Manufacturer | LG Display | Model Name | LP156WF4-SPU1 (LGD03FE) |
|---|---|---|---|
| Screen Size | 15.6 inch | Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) | Outline(mm) | 359.5 × 223.8 × 3.2 (H×V×D) |
| Bezel Area(mm) | 347.6 × 196.9 (H×V) | Treatment | Glare (Haze 0%) |
| Luminance | 330 cd/m² (Typ.) | Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Response | 35 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry | Work Mode | AH-IPS, Normally Black, Transmissive |
| Color Depth | 262K 76% (CIE1931) | Backlight | WLED , 10K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, Depth ≤3.2mm) | Used for |
|
| Refresh Rate | 60Hz | Touchscreen | Without |
| Signal Type | eDP (2 Lanes) , Connector , 30 pins | ||
| Voltage Supply | 3.3V (Typ.) | ||
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | ||
All Origianl product will be send to customer after full test one by one.
|
