| Brand Name: | BOE |
| Model Number: | NT156WHM-N32 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Panel Brand
Panel Model
Panel Size
Panel Type
a-Si TFT-LCD, LCM
Resolution
1366(RGB)×768 , WXGA
Pixel Format
RGB Vertical Stripe
Display Area
344.232(W)×193.536(H) mm
Bezel Opening
-
Outline Size
359.5(W)×223.8(H) ×3.2(D) mm
Surface
Glare (Haze 0%)
Brightness
220 cd/m² (Typ.)
Contrast Ratio
500:1 (Typ.) (TM)
Viewing Angle
45/45/20/40 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
6 o'clock
Response Time
12 (Typ.)(Tr+Td)
Display Colors
262K 45% (CIE1931)
Lamp Type
9S4P WLED , 15K hours , With LED Driver
Frequency
60Hz
Touch Screen
Without
Shape Style
Slim (PCBA Flat, Depth ≤3.2mm)
Application
Signal Interface
eDP (1 Lane) , 30 pins , Connector
Input Voltage
3.3V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
All Origianl product will be send to customer after full test one by one.
|
