BOE 12.3 inch 1920*720 Pixels 850cd Brightness Car LCD Display Automotive TFT-LCD Panel

Name: BOE 12.3 inch 1920*720 Pixels 850cd Brightness Car LCD Display Automotive TFT-LCD Panel
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: AV123Z7M-N12
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	AV123Z7M-N12
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*720

Brightness:

800cd

Connector:

Contrast Ratio:

1100:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

12.3 inch Car LCD Display

1920*720 Pixels Automotive TFT-LCD Panel

850cd Brightness TFT-LCD Display

Product Description

BOE 12.3" 1920×720 Pixels 850cd Brightness 50 Pin Connector Car LCD Display AV123Z7M-N12 Automotive TFT-LCD Panel

The AV123Z7M-N12-58P1 is a 12.3-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integral WLED backlight system without backlight driver or touch screen. This automotive-grade display operates in temperatures from -30°C to 85°C and stores in temperatures from -40°C to 90°C.

Key Features

sRGB color gamut support
Wide temperature operation range
High brightness for outdoor visibility
WLED backlight technology
Bar display format
U/D, L/R reverse capability
Built-in HX8290-A×3 + HX8695×1 driver IC

Technical Specifications

Manufacturer	BOE	Model Name	AV123Z7M-N12-58P1
Display Size	12.3"	Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×720, 8:3	Dot Layout	RGB Vertical Stripe
Display Area	292.032(W)×109.512(H) mm	Surface	Hard coating
Outline Size	307(W)×126(H)×11.3(D) mm	Contrast Ratio	1100:1 (Typ.) (TM)
Brightness	800 cd/m² (Typ.)	Display Mode	ADS, Normally Black, Transmissive
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)	Response Time	25 (Max.)(Tr+Td) mm
View Direction	Symmetry	Touch Screen	Without
Display Colors	16.7M, 72% NTSC	Light Source	9S4P WLED, Without Driver
Frequency	60Hz	Application	Automotive Display
Interface	LVDS (2 ch, 8-bit), 60 pins Connector	Input Voltage	3.5/18/-12.0V (Max.)(VCC/VGH/VGL)
Environment	Operating Temp. -30 ~ 85 °C; Storage Temp. -40 ~ 90 °C	Panel Weight	-

Recommended Applications

Outdoor High Brightness displays
Automotive Display systems

Production status information is for reference only and should not be used as the basis for decision making. For the latest production and specification details, contact BOE or their authorized agents directly.
