Tianma 17.3Inch Industrial LCD Display TFT-LCD Display Panel with 1920x1080Pixels 500cd/m² Brightness and 30pin Connector

Name: Tianma 17.3Inch Industrial LCD Display TFT-LCD Display Panel with 1920x1080Pixels 500cd/m² Brightness and 30pin Connector
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: P1730FHF1MB00
Price: 43.00 USD
Availability: InStock

Brand Name:	TI
Model Number:	P1730FHF1MB00
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*1080Pixels

Brightness:

500cd

Connector:

30pin

Contrast Ratio:

1700:1

Packaging Details:

Industrial packing

Highlight:

1920x1080Pixels Industrial LCD Display

500cd/m² Brightness TFT-LCD Display Panel

30pin Connector LCM

Product Description

Tianma 17.3-Inch Industrial LCD Display P1730FHF1MB00

Product Overview

The Tianma P1730FHF1MB00 is a 17.3-inch industrial-grade TFT-LCD display panel featuring Full HD resolution (1920×1080 pixels), high brightness of 500 cd/m², and a 30-pin LVDS connector. This robust display is designed for demanding industrial applications with wide operating temperature ranges and exceptional reliability.

Technical Specifications

Parameter	Specification
Brand	TIANMA
Model	P1730FHF1MB00
Diagonal Size	17.3 inch
Resolution	1920(RGB)×1080 (FHD), 16:9 aspect ratio
Active Area	381.888(H) × 214.812(V) mm
Physical Size	388.888(H) × 225.812(V) × 9.4(D) mm
Mass	575±28.8g
Brightness	500 cd/m² (Typical)
Contrast Ratio	1700:1 (Typical)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Response Time	35ms (Typical, Tr+Td)
Color Support	16.7M colors, 72% NTSC
Display Type	a-Si TFT-LCD, LCM
Operating Mode	SFT, Normally Black, Transmissive
Dot Layout	RGB Vertical Stripe
Surface Coating	Antiglare, Matte
Interface Type	LVDS (2 ch, 8-bit), 30-pin Connector
Power Supply	5.0V (Typical)
Frame Rate	60Hz
Backlight System	WLED, 30K hours lifespan, With LED Driver
Touch Panel	Without

Environmental Specifications

Parameter	Specification
Operating Temperature	-20°C to 70°C
Storage Temperature	-20°C to 80°C

Key Features

Industrial-grade reliability with wide temperature operation
High brightness (500 cd/m²) for various lighting conditions
Full HD resolution for sharp image quality
WLED backlight with 30,000-hour lifespan
Antiglare surface coating for reduced reflections
LVDS interface with 30-pin connector
Designed for industrial applications

Note: Mass production is scheduled for Q3 2025. This model is currently in production. For the latest production status and detailed specifications, please contact TIANMA or their authorized distributors. The information provided is for reference only and should not be used as the sole basis for decision-making.
