10.1Inch Industrial LCD Display TFT-LCD Screen with 1280×800 Pixels Resolution 500cd/m² Brightness and 40pin Connector

Name: 10.1Inch Industrial LCD Display TFT-LCD Screen with 1280×800 Pixels Resolution 500cd/m² Brightness and 40pin Connector
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: GV101WXM-N80
Price: 43.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	GV101WXM-N80
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

1280*800pixels

Style:

40PIN IPS

Brightness:

500CD/M2

Color:

16.7M

Working Life:

30K Hours

Interface:

LVDS

Packaging Details:

Industrial packing

Highlight:

1280×800 Pixels Resolution Industrial LCD Display

500cd/m² Brightness TFT-LCD Screen

40pin Connector LCD Panel

Product Description

10.1-Inch Industrial LCD Panel GV101WXM-N80

The GV101WXM-N80 is a 10.1-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integral WLED backlight system with LED driver and no touch screen. This industrial-grade display operates within a temperature range of -20°C to 70°C and is recommended for industrial applications.

Key Specifications

Manufacturer	BOE	Model No.	GV101WXM-N80
Screen Size	10.1 inch	Screen Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)×800, WXGA	Aspect Ratio	16:10
Active Area	216.96×135.6 mm (H×V)	Outline Area	228.2×148.85×4.9 mm (H×V×D)
Brightness	500 cd/m² (Typ.)	Contrast Ratio	1300:1 (Typ.)
Viewing Angle	85/85/85/85 (Typ.)	Response Time	30ms (Typ.)
Display Type	ADS, Normally Black, Transmissive	Display Colors	16.7M, 45% NTSC
Backlight	WLED, 30K hrs lifespan	Touchscreen	Without
Signal Type	LVDS (1 ch, 8-bit), eDP1.2, HBR1 (2.7G/lane)	Connector	40 pins
Operating Voltage	3.3V (Typ.)	Weight	150g (Max.)

Environmental Specifications

Operating Temperature: -20°C to 70°C
Storage Temperature: -30°C to 80°C
Surface Feature: Hard coating (3H)
Refresh Rate: 60Hz

Mass production began in Q4 2023. For the latest production status and detailed specifications, we strongly recommend contacting BOE or their authorized agents directly. The information provided here is for reference only and should not be used as the sole basis for decision-making.
