LG 4.8Inch Car LCD Display with 400 cd/m² Luminance 240 × 257 Pixel Number and 40PIN Connector for Automotive

Name: LG 4.8Inch Car LCD Display with 400 cd/m² Luminance 240 × 257 Pixel Number and 40PIN Connector for Automotive
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LB048Q01-TD01
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LB048Q01-TD01
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass

Brightness:

400ccd/m2

Resolution:

240*357pixels

Contrast Ratio:

400:1

Color:

262K

Working Life:

20k Hours

Connector:

40P

Touch Panel:

Without

Packaging Details:

Industrial packing

Highlight:

400 cd/m² Luminance Car LCD Display

240 × 257 Pixel Number TFT-LCD Display

40PIN Connector LCM Display

Product Description

LG 4.8-Inch Car LCD Display LB048Q01-TD01

High-brightness 4.8-inch automotive LCD display with 400 cd/m² luminance and 240 × 257 resolution, featuring a 40-pin square screen interface.

Product Overview

The LB048Q01-TD01 is a 4.8-inch diagonal a-Si TFT-LCD display panel from LG Display Co., Ltd. This portrait-type display features an integral WLED backlight system and is designed for wide temperature operation. It's particularly suited for automotive display applications and square display formats.

Note: This model entered mass production in Q1 2009 and is currently discontinued. For integration into future products, contact LG Display or their agent for the latest production and specification details.

Technical Specifications

Manufacturer	LG Display
Model Name	LB048Q01-TD01
Display Size	4.8 inch
Panel Type	a-Si TFT-LCD, LCM
Resolution	240(RGB)×257, 1:1
Pixel Structure	RGB Vertical Stripe
Display Area	83.016(W)×88.922(H) mm
Panel Weight	195/200g (Typ./Max.)
Outline Size	93.1(W)×100.8(H)×34.4(D) mm
Brightness	400 cd/m² (Typ.)
Contrast Ratio	610:1 (Typ.) (TM)
Viewing Angle	70/70/50/60 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
View Direction	6 o'clock
Response Time	16/16 (Max.)(Tr/Td) ms
Display Colors	262K, 63% NTSC
Application	Automotive Display
Frequency	60Hz
Touch Screen	Without
Light Source	2S3P WLED, 20K hrs, Without Driver
Interface	Parallel RGB (1 ch, 6-bit), 40 pins Connector
Input Voltage	3.3V (Typ.)
Operating Temperature	-40 ~ 85 °C
Storage Temperature	-40 ~ 95 °C
Vibration	3.0G (29.4 m/s²)

The production status information provided is for reference only and should not be used as the basis for user decision-making. Always verify current specifications with the manufacturer.
