BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen

Name: BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: DV290FBM-N10
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	DV290FBM-N10
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7m Colors

Model:

WLED

Style:

Wide Screen High Resolution 1920*540pixels

Brightness:

700cd

Connector:

51pin

Contrast Ratio:

1200:1

Working Life:

50K Hours

Signal Interface:

LVDS

Input Voltage:

12V

Packaging Details:

Industrial packing

Highlight:

700cd/m2 Brightness Stretched LCD Display

1920*540 Pixels Resolution Bar LCD Display

Outdoor High Bright Digital Signage Screen

Product Description

BOE 29-Inch Stretched LCD Display DV290FBM-N10

High-brightness 29-inch stretched LCD display with 700 cd/m² brightness and 1920×540 resolution, designed for outdoor digital signage applications.

Product Overview

BOE Technology Group Co., Ltd. DV290FBM-N10 is a 29.0-inch diagonal a-Si TFT-LCD display panel featuring an integral WLED backlight system. This landscape/portrait compatible bar display offers high brightness performance with matte surface coating, making it ideal for digital signage, outdoor high-brightness applications, and stretched bar LCD implementations.

Technical Specifications

Brand	BOE
Model	DV290FBM-N10
Diagonal Size	29.0 inch (Native bar)
Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×540 pixels (>3:1 aspect ratio)
Pixel Structure	RGB Vertical Stripe
Active Area	705.6(H)×198.45(V) mm
Physical Size	720.8(H)×226.25(V)×21.6(D) mm
Weight	2.15±0.1 kg
Surface Coating	Antiglare (Haze 25%), Hard coating (3H)
Brightness	700 cd/m² (Typical)
Contrast Ratio	1200:1 (Typical)
Response Time	15 ms (Typical, G to G)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Operating Mode	HADS, Normally Black, Transmissive
Color Support	16.7M colors, 72% NTSC
Power Consumption	40.66W (Typical)
Light Source	WLED, 50K hours lifespan, Without Driver
Frame Rate	60Hz
Touch Panel	Without
Interface	LVDS (2 ch, 8-bit), 51 pins Connector
Power Supply	12.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Note: Production status information is for reference only. For the latest production and specification details, please contact BOE or its authorized distributors before integrating the DV290FBM-N10 into your products.
