BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Brand Name:	BOE
Model Number:	DV280FBM-NB1
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

16.7M

Model:

LCM,TFT

Style:

Bar Lcd Display

Resolution:

1920*360pixels

Brightness:

700CCD/M2

Connector:

51Pin

Working Life:

50k Hours

Contrast Ratio:

1200:1

Screen Size:

28inch

Supply Ability:

3000pcs per week

Product Description

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

DV280FBM-NB1 is a 28.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: Hight Brightness, WLED Backlight, Life ≥ 50K hours, Bar Display , 1/3 cut of 31.5". Based on its features, Einklcd recommend that this model be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc. According to the information stored in einklcd this model mass production on Q1, 2016, Now this model is in production. We inputted this model's specification on May 23 2016 for the first time, and the latest update on Sep 5 2025. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of DV280FBM-NB1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:BOE

Model P/N: DV280FBM-NB1

Diagonal Size 28.0" (1/3 cut of 32.0")

Panel Type: a-Si TFT-LCD, LCM

Resolution1920(RGB)×360 69PPI Pixel

Format RGB Vertical Stripe

Active Area 699.84(W)×131.22(H) mm

Bezel Opening 704(W)×136(H) mm

Outline Size: 732(W)×165(H) ×17.3(D) mm

Brightness:700 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors: 16.7M 72% NTSC

Frequency 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 2.40Kgs (Typ.)

Surface

Contrast Ratio:1200:1 (Typ.) (TM)

Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time :8 (Typ.)(G to G)

Lamp Type: WLED , 50K hours , Without Driver

Touch Screen :Without

Application:Digital Signage Outdoor High Brightness Stretched Bar LCD

Signal Interface LVDS (1 ch, 8-bit) , 51 pins Connector

Input Voltage 12.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C
