BOE 23.6inch Stretched LCD Display with 1280*1280pixels Resolution and 1500cd/m² Brightness for Digital Signage

Name: BOE 23.6inch Stretched LCD Display with 1280*1280pixels Resolution and 1500cd/m² Brightness for Digital Signage
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: DV236FBM-N00
Price: 30.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	DV236FBM-N00
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

16.7M

Model:

LCM,TFT

Style:

Bar Lcd Display

Resolution:

1280*1280pixels

Brightness:

1500CCD/M2

Connector:

30Pin

Working Life:

50k Hours

Contrast Ratio:

1000:1

Packaging Details:

Industrial packing

Highlight:

DV236FBM-N00 Digital signage LCD Display

12V Digital signage LCD Display

30Pin Digital signage LCD Display

Product Description

BOE 23.6-inch Digital Signage LCD Display DV236FBM-N00

The DV236FBM-N00 is a 23.6-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integral WLED backlight system with LED driver. This circular display offers ultra-high brightness and is designed for demanding outdoor applications.

Key Features

Circular display design with 23.6-inch diagonal
Ultra-high brightness: 1500 cd/m² (typical)
WLED backlight with 50,000+ hours lifespan
Integrated LED driver included
Matte surface treatment with anti-glare (Haze 25%)
Wide viewing angles: 89/89/89/89 (CR≥10)
High refresh rate options up to 240Hz
16.7 million colors with 72% NTSC color gamut

Technical Specifications

Model Number	DV236FBM-N00
Panel Type	a-Si TFT-LCD, LCM
Resolution	1280 * 1280 pixels (54 PPI)
Active Area	599.424 * 599.424 mm
Outline Dimensions	657 * 657 * 29.15 mm
Brightness	1500 cd/m² (typical)
Contrast Ratio	1000:1 (typical)
Response Time	14 ms (G to G, typical)
Refresh Rate	60Hz standard, up to 240Hz with MEMC
Interface	LVDS (2 ch, 8-bit), 30-pin connector
Power Supply	12V DC (typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Vibration Resistance	Max. 1.5G (14.7 m/s²)

Applications

Digital signage displays
Outdoor high-brightness applications
Round display solutions
Public information displays

Note: This model entered mass production in Q2 2022 and is currently in production. For the latest production status and detailed specifications, we recommend contacting BOE or their authorized agents directly.
