BOE 19.1inch Stretched LCD Display with 1920*360pixels Resolution and 700 cd/m² Brightness Featuring 30Pin Connector

BOE 19.1inch Stretched LCD Display with 1920*360pixels Resolution and 700 cd/m² Brightness Featuring 30Pin Connector

Brand Name:	BOE
Model Number:	QV190FBM-N10
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Led

Color:

16.7M

Model:

LCM,TFT

Style:

Bar Lcd Display

Resolution:

1920*360pixels

Brightness:

700CCD/M2

Connector:

30Pin

Working Life:

30k Hours

Contrast Ratio:

1200:1

Packaging Details:

Industrial packing

Highlight:

19.1inch Stretched LCD Display

1920*360pixels Stretched LCD Display

Glass LED Stretched LCD Display

Product Description

BOE 19.1-inch Stretched LCD Display

High-brightness 19.1-inch stretched LCD panel with 1920*360 resolution, designed for outdoor digital signage and bar display applications.

Key Features

High brightness: 700 cd/m² for outdoor visibility
Stretched bar display format: 1920*360 resolution
WLED backlight with 30,000-hour lifespan
120Hz refresh rate with embedded MEMC circuit
Wide viewing angle: 89/89/89/89 (CR≥10)
Energy Star 6.0 compliant
Designed for digital signage and outdoor applications

Technical Specifications

Brand & Model	BOE QV190FBM-N10C
Diagonal Size	19.1 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)*360 pixels (102 PPI)
Active Area	476.64mm (W) * 89.37mm (H)
Outline Dimensions	491.5mm (H) * 109.4mm (V) * 13.3mm (D)
Brightness	700 cd/m² (Typical)
Contrast Ratio	1200:1 (Typical)
Response Time	30ms (Typical, Tr+Td)
Viewing Angle	89/89/89/89 (Left/Right/Up/Down)
Operating Mode	ADS, Normally Black, Transmissive
Color Support	16.7M colors, 72% NTSC
Interface	LVDS (2 ch, 8-bit), 30-pin connector
Power Supply	5.0V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Weight	780g (Typical)

Refresh Rate Options

60Hz standard operation
120Hz (60Hz input) with embedded MEMC circuit
120Hz+120Hz: 120Hz panel + 120Hz backlight
240Hz (60Hz input) with embedded MEMC circuit

Note: This model entered mass production in Q1 2024. For the latest production status and detailed specifications, please contact BOE or their authorized distributors. Information provided is for reference only and should not be used as the sole basis for decision-making.
