Hitachi 6.2Inch Industrial LCD Display 640X240Pixels 90cd/M2 24PIN LCM CSTN-LCD Panel

Name: Hitachi 6.2Inch Industrial LCD Display 640X240Pixels 90cd/M2 24PIN LCM CSTN-LCD Panel
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: SX16H006-ZZA
Price: 43.00 USD
Availability: InStock

Brand Name:	Hitachi
Model Number:	SX16H006-ZZA
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

Japan

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

640*240pixels

Resolution:

640*240pixels

Style:

24PIN IPS

Style:

24PIN IPS

Brightness:

90CD/M2

Brightness:

90CD/M2

Color:

262k

Contrast Ratio:

350 :1

Working Life:

50K Hours

Type:

Lcm

Size:

6.2inch

Lamp Type:

WLED

Voltage:

3.3V

Model Numberer:

SX16H006-ZZA

Packaging Details:

Industrial packing

Highlight:

Hitachi 6.2Inch Industrial lcd

SX16H006-ZZA Industrial lcd

90cd/M2 Industrial lcd

Product Description

Hitachi 6.2-Inch Industrial LCD Display SX16H006-ZZA

The Hitachi SX16H006-ZZA is a 6.2-inch diagonal CSTN-LCD display panel designed for industrial applications. This panel features an integrated CCFL backlight system, 4-wire resistive touchscreen, and operates within a temperature range of 0-50°C.

Product Overview

Manufactured by Kaohsiung Hitachi Electronics Co., Ltd., this industrial LCD panel offers 640*240 pixel resolution (109 PPI) with 90 cd/m² brightness. The panel includes a built-in 4-wire resistive touch interface and is designed for reliable performance in demanding environments.

Key Features

6.2-inch CSTN-LCD display with 640*240 resolution
4-wire resistive touchscreen interface
Integrated CCFL backlight with 50,000-hour lifespan
Industrial temperature range: 0°C to 50°C operating
Bar display format suitable for industrial applications
24-pin connector with parallel data interface

Technical Specifications

Brand	HITACHI
Model Number	SX16H006-ZZA
Diagonal Size	6.2 inches
Panel Type	CSTN-LCD, LCM
Resolution	640(RGB)*240, HVGA 109PPI
Active Area	148.8*53.76 mm
Brightness	90 cd/m² (Typical)
Contrast Ratio	30:1 (Typical)
Viewing Angle	45/45/40/40 (Typical, CR≥2)
Display Colors	Color 28% NTSC
Response Time	250/200 ms (Typical, Tr/Td)
Backlight	1 CCFL, 50K hours, Without Driver
Touch Screen	4-wire Resistive Touch
Interface	Parallel Data (1ch, 8-bit), 24-pin Connector
Input Voltage	3.3V (Typical)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Panel Weight	140g (Typical)
Outline Dimensions	173708.5 mm

Product Images

Important Note: This model began mass production in Q2 2003 and is currently discontinued. The information provided is for reference only. For integration into new products, please contact Hitachi or their authorized distributors for the latest production status and specifications.
