| Brand Name: | AUO |
| Model Number: | M240uan01.0 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
AUO 24Inch Industrial lcd model M240uan01.0 1920X1200P 94PPI 300cd/M2 30PIN Desktop lcd
The M240UAN01.0 is a 24.0 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcdin the following: sRGB, WLED Backlight, Upside I/F, Matte , TCO 7.0 Compliance. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Industrial etc. According to the information stored in einklcd this model mass production on Q3, 2018, Now this model is in production. We inputted this model's specification on Jul 7 2016 for the first time, and the latest update on Aug 3 2023. If you want to embed M240UAN01.0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The M240UAN01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
| Outline Size | 546.4(W)×352(H) ×12.2(D) mm | Surface | Antiglare (Haze 25%) |
|---|---|---|---|
| Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 100% sRGB | Lamp Type | 10S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz | Touch Screen | Without |
| Panel Weight | 2.53Kgs (Typ.) | Application | |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Input Voltage | 12.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
|
|
