BOE 18.5inch Industrial LCD Panel with 1920x1080 Resolution 350 cd/m² Brightness and 30pin LVDS Interface

Name: BOE 18.5inch Industrial LCD Panel with 1920x1080 Resolution 350 cd/m² Brightness and 30pin LVDS Interface
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: GV185FHM-N10-3M30
Price: 43.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	GV185FHM-N10-3M30
MOQ:	10PCS
Price:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	30K pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROSH,UL,FCC

Material:

Glass

Voltage:

5.0 V

Brightness:

350cd

Resolution:

1920*11080pixels

Interface Type:

30pin LVDS

Contrast Ratio:

1200:1

Working Life:

50k Hour

Light Source:

WLED

Packaging Details:

industrial package

Highlight:

BOE Industrial Lcd Monitor

18.5inch Industrial Lcd Panel

350 Cd/M2 Industrial Lcd Panel

Product Description

BOE 18.5-inch Industrial LCD Panel

The GV185FHM-N10-3M30 from BOE Technology Group is a high-performance 18.5-inch industrial LCD panel featuring Full HD resolution and wide temperature operation capabilities.

Product Specifications

Brand	BOE
Model	GV185FHM-N10-3M30
Diagonal Size	18.5 inch
Display Type	a-Si TFT-LCD, LCM
Resolution	1920*1080 (FHD) - 119 PPI
Pixel Configuration	RGB Vertical Stripe
Active Area	408.96(H) * 230.04(V) mm
Outline Dimensions	430.4(H) * 254.6(V) * 12.5(D) mm
Bezel Area	410.96(H) * 232.04(V) mm
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Brightness	350 cd/m² (Typical)
Contrast Ratio	1200:1 (Typical)
Viewing Angle	85/85/85/85 (CR≥10)
Response Time	30 ms (Typical, Tr+Td)
Operating Mode	ADS, Normally Black, Transmissive
Color Support	16.7M colors, 70% NTSC
Backlight	WLED [11S4P], With LED Driver
Weight	1.80 kg (Typical)
Frame Rate	60Hz
Touch Panel	Without
Interface	LVDS (2 ch, 8-bit), 30 pins Connector
Power Supply	5.0V (Typical)
Operating Temperature	-30°C to 80°C
Storage Temperature	-30°C to 80°C

Key Features

Wide temperature operation range (-30°C to 80°C)
Integrated WLED backlight system with driver
Full HD 1920*1080 resolution
Industrial-grade construction and reliability
High brightness 350 cd/m² display
Antiglare surface treatment with hard coating

Production Status: Currently in production (since Q2 2020). For the latest production status and specifications, please contact BOE or their authorized distributors.

Application Recommendations

This industrial LCD panel is specifically designed for demanding applications including industrial equipment, control systems, and other environments requiring reliable performance across wide temperature ranges.
