10.1 Inch WSVGA 117PPI Industrial Lcd Screen AUO G101STN01.0 250cd/M2

AUO G101STN01.0 10.1inch Industrial Lcd Display 1024(RGB)×600 (WSVGA) 117PPI 3.3V 4P WLED 250 cd/m² 16.7M color

AU Optronics Corp. (hereafter called AUO) G101STN01.0 is a 10.1 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -10 ~ 60°C , a storage temperature range of -30 ~ 70°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: WLED Backlight, With LED Driver, Reverse I/F, 6/8 bit, Matte . Based on its features, einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q1, 2015, Now this model is in production.  We inputted this model's specification on Apr 17 2014 for the first time, and the latest update on Aug 8 2019. If you want to embed G101STN01.0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The G101STN01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Manufacturer

AUO

Model Name

G101STN01.0

Screen Size

10.1 inch

Screen Type

LCM , a-Si TFT-LCD

Pixel Number

1024(RGB)×600 (WSVGA) 117PPI

Arrangement

RGB Vertical Stripe

Active Area(mm)

222.72 × 125.28 (H×V)

Outline(mm)

235 × 143 × 5.2 (H×V×D)

Bezel Area(mm)

226.34 × 128.1 (H×V)

Treatment

Antiglare, Hard coating (3H)

Luminance

250 cd/m² (Typ.)

Contrast Ratio

500 : 1 (Typ.) (TM)

Viewing Angle

70/70/60/60 (Typ.)(CR≥10)

Response

7/9 (Typ.)(Tr/Td) ms

Good View at

-

Work Mode

TN, Normally White, Transmissive

Color Depth

262K/16.7M 45% NTSC

Backlight

WLED , 15K hours , With LED Driver

Mass

180g (Typ.)

Used for

Refresh Rate

60Hz

Touchscreen

Without

Signal Type

LVDS (1 ch, 6/8-bit) , 40 pins Connector

Voltage Supply

3.3V (Typ.)

Max. Ratings

Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C
