10.4" 800×600 96PPI 400cd/m2 Industrial Lcd Screen G104STN01.0

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  10.4" 800×600 96PPI 400cd/m2 Industrial Lcd Screen G104STN01.0

Product Details:
Place of Origin: China
Brand Name: auo
Certification: Rohs,CE,FCC
Model Number: G104STN01.0
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 265K Colors
Model: WLED Style: Wide Screen High Resolution 800(RGB)×600 [QVGA] 122PPI
Brightness: 400cd Connector: 20PIN
Contrast Ratio: 700:1 Working Time: 70k Hours
High Light:

96PPI Industrial Lcd Screen


400cd/m2 Industrial Lcd Screen



AUO 10.4inch industrial lcd panel 800(RGB)×600 [SVGA] 96PPI 400cd/m2 700:1 contrast ratio 20Pin 262k colors


AU Optronics Corp. (hereafter called AUO) G104STN01.0 is a 10.4 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: Wide Temperature, WLED Backlight, Life ≥ 70K hours, With LED Driver, 180° Reverse, 6/8 bit, Matte . Based on its features, Einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q1, 2014, Now this model is in production.  We inputted this model's specification on Oct 16 2013 for the first time, and the latest update on Apr 8 2020. If you want to embed G104STN01.0 LCM in your future product, Einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The G104STN01.0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


10.4" 800×600 96PPI 400cd/m2 Industrial Lcd Screen G104STN01.0 010.4" 800×600 96PPI 400cd/m2 Industrial Lcd Screen G104STN01.0 1



Diagonal Size
10.4 inch
Pixel Format
800(RGB)×600 [SVGA] 96PPI
RGB Vertical Stripe
Active Area
211.2(H)×158.4(V) mm
Outline Dim.
243(H)×184(V) ×7(D) mm
Bezel Area
214.8(H)×162.7(V) mm
Antiglare, Hard coating (3H)
400 cd/m² (Typ.)
Contrast Ratio
700:1 (Typ.) (TM)
View Direction
Response Time
10/5 (Typ.)(Tr/Td)
Viewing Angle
80/80/60/70 (Typ.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Support Color
262K/16.2M 50% NTSC
Light Source
WLED [7S2P] , 70K hours , With LED Driver
365g (Typ.)
Designed For
10.4" 800×600 96PPI 400cd/m2 Industrial Lcd Screen G104STN01.0 2
Frame Rate
Touch Panel
Interface Type
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply
3.3V (Typ.)
Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C
