6.5" 640×480 VGA 122PPI 800cd/m2 Industrial LCD Monitor Panel TFT-LCD Display

6.5" 640×480 VGA 122PPI 800cd/m2 Industrial LCD Monitor Panel TFT-LCD Display

Brand Name:	auo
Model Number:	G065VN01 V2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

265K Colors

Model:

Style:

Wide Screen High Resolution 640(RGB)×480 [QVGA] 122PPI

Brightness:

800cd

Connector:

20PIN

Contrast Ratio:

600:1

Working Time:

50k Hours

Packaging Details:

Industrial packing

Highlight:

800cd/m2 Industrial Lcd Monitor

640×480 Industrial Lcd Monitor

G065VN01 V2

Product Description

6.5" 640×480 VGA 122PPI 800cd/m² Industrial LCD Monitor G065VN01 V2

AUO 6.5-inch industrial LCD panel featuring 640(RGB)×480 VGA resolution, 122PPI pixel density, 800cd/m² brightness, and 600:1 contrast ratio with 262K colors.

Product Overview

The G065VN01 V2 is a 6.5" diagonal a-Si TFT-LCD display panel from AU Optronics Corp. featuring an integral WLED backlight system with LED driver. This industrial-grade panel operates in extreme temperature conditions and is designed for demanding applications.

Key Features

Wide operating temperature range (-30°C to 80°C)
High brightness 800cd/m² display
Replaceable backlight lamps
WLED backlight with ≥50,000 hours lifespan
Built-in LED driver
U/D, L/R reverse functionality
6/8-bit color depth support
Glossy surface with hard coating (3H)
EcoTR technology

Technical Specifications

Panel Brand	AUO
Panel Model	G065VN01 V2
Panel Size	6.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	640(RGB)×480, VGA, 122PPI
Pixel Format	RGB Vertical Stripe
Display Area	132.48(W)×99.36(H) mm
Bezel Opening	135.9(W)×102.8(H) mm
Outline Size	153(W)×118(H)×11.2(D) mm
Surface	Glare (Haze 0%), Hard coating (3H), Antireflection
Brightness	800 cd/m² (Typical)
Contrast Ratio	600:1 (Typical)
Viewing Angle	80/80/70/70 (Typical, CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View	6 o'clock
Response Time	15/10 (Typical, Tr/Td)
Display Colors	262K/16.2M, 55% NTSC
Backlight Type	WLED, 50K hours, With LED Driver
Refresh Frequency	60Hz
Touch Screen	Without
Panel Weight	170g (Typical)
Signal Interface	LVDS (1 ch, 6/8-bit), 20 pins Connector
Input Voltage	3.3V (Typical)
Operating Temperature	-30°C to 80°C
Storage Temperature	-30°C to 80°C

Application Areas

This industrial LCD panel is recommended for industrial applications and outdoor high-brightness environments where reliable performance in extreme conditions is required.

Note: Mass production began in Q4 2009 and this model is currently in production. For the latest production status and detailed specifications, please contact AUO or their authorized agents directly.
