Toshiba 8.4 inch Industrial LCD Monitor with 800×600 SVGA Resolution and 145cd/m2 Brightness

Name: Toshiba 8.4 inch Industrial LCD Monitor with 800×600 SVGA Resolution and 145cd/m2 Brightness
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LTM08C355S
Price: 43.00 USD
Availability: InStock

Brand Name:	TOSHIBA
Model Number:	LTM08C355S
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

262Kcolors

Model:

WLED

Style:

Wide Screen High Resolution 800*600Pixels

Brightness:

145cd

Connector:

Contrast Ratio:

250:1

Working Time:

30k Hours

Packaging Details:

Industrial packing

Highlight:

145cd/m2 Industrial Lcd Monitor

800×600 Industrial Lcd Monitor

LTM08C355S

Product Description

Toshiba 8.4" 800*600 119PPI Industrial LCD Monitor

Toshiba 8.4-inch LCD model for laptop industrial panel display with 800(RGB)*600 [SVGA] resolution, 119PPI density, 30-pin interface, and 145cd/m² brightness.

Product Specifications

Brand: TOSHIBA

Model: LTM08C355S

Diagonal Size: 8.4 inch

Type: LTPS TFT-LCD, LCM

Pixel Format: 800(RGB)*600 [SVGA] 119PPI

Configuration: RGB Vertical Stripe

Active Area: 170.4(H)*127.8(V) mm

Outline Dimensions: 200.3(H)*140.3(V)*5.5(D) mm

Bezel Area: 173.4(H)*130.8(V) mm

Luminance: 145 cd/m² (Typ.)

Contrast Ratio: 250:1 (Typ.) (TM)

Response Time: 50/50 (Max.)(Tr/Td)

Operating Mode: TN, Normally White, Transmissive

Support Color: 262K

Light Source: CCFL [1 pcs], W/O Driver

Frame Rate: 60Hz

Touch Panel: Without

Interface Type: Parallel RGB (1 ch, 6-bit), 30 pins Connector

Power Supply: 3.3V (Typ.)(VDD)

Operating Temperature: 0 ~ 50 °C

Storage Temperature: -20 ~ 60 °C

Key Features

8.4-inch diagonal LTPS TFT-LCD display panel
Integral CCFL backlight system
SVGA 800*600 resolution with 119PPI density
30-pin parallel RGB interface
Wide operating temperature range

Quality Assurance: All LCD panels undergo comprehensive individual testing before delivery and include a one-year warranty.

Product Status Note: This Toshiba LTM08C355S model entered mass production in Q2 2001 and is currently discontinued. Panelook recommends contacting Toshiba or their distributor for the latest production and specification details before integration into future products.
