| Brand Name: | CPT |
| Model Number: | CLAA102NA0DCW |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
Panel Brand
CPT
Panel Model
CLAA102NA0DCW
Panel Size
10.2"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1024(RGB)×600 , WSVGA
Pixel Format
RGB Vertical Stripe
Display Area
222.72(W)×130.5(H) mm
Bezel Opening
225.90(W)×134.2(H) mm
Outline Size
235(W)×145.8(H) ×5.5(D) mm
Surface
Antiglare, Hard coating (3H)
Brightness
400 cd/m² (Typ.)
Contrast Ratio
400:1 (Typ.) (TM)
Viewing Angle
70/70/50/70 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
6 o'clock
Response Time
20 (Typ.)(Tr+Td)
Display Colors
262K 50% (CIE1931)
Lamp Type
WLED , 2K hours , With LED Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
250g (Typ.)
Application
Signal Interface
LVDS (1 ch, 6-bit) , 30 pins , Connector
Input Voltage
3.3V (Typ.)
Environment
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²)
The CLAA102NA0DCW is a 10.2 inch diagonal a-Si TFT-LCD display panel product from Chunghwa Picture Tubes, LTD. (hereafter called CPT), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 2.9G (28.4 m/s²). It's general features are summarized by einklcd in the following: Antiglare Surface, Landscape type, 3G Vibration Resistance, White LED Backlight, Wide Aspect Ratio . Based on its features, einklcd recommend that this model be applied to Automotive Display etc. According to the information stored in einklcd this model mass production on Q3, 2010 and last shippment on Q3, 2015, Now this model is discontinued.. We inputted this model's specification on Feb 7 2013 for the first time, and the latest update on Dec 29 2015. If you want to embed CLAA102NA0DCW LCM in your future product, einklcd strongly recommend that you should contact with CPT or it's agent to learn lateast production and specification detail. The CLAA102NA0DCW production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
|
|
