Innolux 8" Industrial LCD Display with 1200*1920 Resolution and 300cd/m2 Brightness TFT-LCD Panel

Name: Innolux 8" Industrial LCD Display with 1200*1920 Resolution and 300cd/m2 Brightness TFT-LCD Panel
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: P080LDN-DB2
Price: 43.00 USD
Availability: InStock

Brand Name:	innolux
Model Number:	P080LDN-DB2
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W,Western Union,MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

WLED

Style:

Wide Screen High Resolution 1200*1920

Brightness:

300cd

Connector:

Contrast Ratio:

900:1

Working Time:

50k Hours

Packaging Details:

Industrial packing

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

Notebook PC Industrial LCD Display Innolux 8" 1200*1920 Pixels P080LDN-DB2

Panel Specifications

Panel Brand Innolux

Panel Model P080LDN-DB2

Panel Size 8.0 inches

Panel Type a-Si TFT-LCD Assembly

Resolution 1200(RGB)*1920 (WUXGA)

Pixel Format RGB Vertical Stripe

Display Area 107.64(W)*172.224(H) mm

Outline Size 120.54(W)*207.15(H) mm

Brightness 290 cd/m² (Typical)

Contrast Ratio 900:1 (Typical)

Viewing Angle 80/80/80/80 (Typical, CR≥10)

Display Mode IPS, Normally Black, Transmissive

Best View Symmetry

Response Time 25ms (Typical, Tr+Td)

Display Colors 16.7M 70% (CIE1931)

Lamp Type 6S4P WLED, Without Driver

Frequency 60Hz

Touch Screen PCAP, On-Cell

Panel Weight 130g (Maximum)

Interface & Power Specifications

Signal Interface MIPI (4 data lanes), 44 pins, Connector

Input Voltage 1.8/3.3V (Typical, VDDIO/VDD)

Key Features

High-resolution WUXGA display for crisp image quality
IPS technology for wide viewing angles
Projected capacitive touch screen (PCAP) with on-cell technology
Industrial-grade construction for reliable performance
Compact 8-inch form factor ideal for notebook PC applications

All specifications are typical values unless otherwise noted. Actual performance may vary depending on application conditions.
