| Brand Name: | sharp |
| Model Number: | LQ104S1DG21 |
| MOQ: | 10pcs |
| Price: | Negotiation |
| Packaging Details: | Industrial packing |
| Payment Terms: | T/T,W, Western Union, MoneyGram |
| Manufacturer | Sharp | Model Name | LQ104S1DG21 |
|---|---|---|---|
| Screen Size | 10.4 inch | Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 800(RGB)×600 (SVGA) | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 211.2 × 158.4 (H×V) | Outline(mm) | 246.5 × 179.4 (H×V×D) |
| Bezel Area(mm) | 214.6 × 162.4 (H×V) | Treatment | Antiglare, Hard coating (3H), Antireflection |
| Luminance | 350 cd/m² (Typ.) | Contrast Ratio | 300 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/40/70 (Typ.)(CR≥10) | Response | 10/25 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock | Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K | Backlight | 2 pcs CCFL , 50K hours , No Driver |
| Mass | 620g (Max.) | Used for |
|
| Refresh Rate | - | Touchscreen | Without |
| Signal Type | CMOS (1 ch, 6-bit) , Connector , 41 pins | ||
| Voltage Supply | 3.3/5.0V (Typ.)(VCC) | ||
| Max. Ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 65 °C | ||
LQ104S1DG21 is a 10.4" diagonal a-Si TFT-LCD display panel product from Sharp Corporation (hereafter called Sharp), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of -10 ~ 65°C , a storage temperature range of -30 ~ 70°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by einklcd in the following: Antiglare Surface, Landscape type, Lamp Repaceable, Lamp life ≥ 50K hours, U/D,L/R Reverse , LAST SHIP DATE:8 July 2011. Based on its features, einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q2, 2003 and last shippment on Q3, 2011, Now this model is discontinued. We inputted this model's specification on Aug 23 2012 for the first time, and the latest update on May 31 2015. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with Sharp or it's agent to learn lateast production and specification detail of LQ104S1DG21. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
|
|
